Instructions for Use

EasyThru® Closed Suction Catheters-72 Hours（L Style）

Product model:Child type (6Fr, 8Fr) and Adult type (10Fr, 12Fr, 14Fr, 16Fr)

Product performance:

- The product is made of high quality medical PVC.

- Soft Blue tip design for adult type reduces irritation and damage to the tracheal mucosa.

- The product uses several closed designs and additional cleaning function. It can effectively avoid the risk of caregiver being infected by the air exhaled

  by the patient during the treatment process.

- In clinical use, the flushing port with a one-way valve design to prevent liquid reflux after flushing.

- This design makes the Closed Suction Catheter tube more convenient, safety and easier to operate by caregiver.

- The black indicator line indicates the position of the withdrawal suction tube to avoid the ETT airway block.

- Closed Suction Catheter should be free of sensitization and mucosal irritation, the Cytotoxicity is not more than level 2. The products will sterilization by EO.

Main product structures:

The main parts include Y-piece Double Swivel Elbow Connector, Transfer connector, Flex catheter mount, double-position Push Switch, PU Sleeve cover, PVC

Suction Catheter, Flushing irrigation port, Medicine Injection port, Negative pressure thumb control valve, Suction Tube Connector and so on.
